Additional information
Modello |
K500040 |
---|---|
Max. delivery |
12 l/min |
Air pressure range |
3-7 bar / 40-100 psi |
Max. fluid outlet pressure |
380 bar – 5.510 psi |
Delivery per cycle |
200 cc |
Air consumption at 60 cycles / min |
3 bar – 2.200 l/min |
Air supply inlet |
3/4″ BSPP (M) |
Fluid outlet |
1″ BSPP (F) |
Materiale pompante |
Acciaio al carbonio |
Piston material |
Stainless steel 420B |
Seals material |
PTFE + PE 1000 |
Effective motor diameter |
Ø 10″ – 250 mm |
Piston stroke |
Ø 4 3/4″ – 120 mm |
Max. temperatura d'esercizio |
80 °C |
Capacità fusto |
30 l |
Max. altezza fusto |
480 mm |
Piatto premente |
Cod. 510750 |
Elevatore pneumatica |
Cod. 510090/1 |
Altezza sistema completo |
1.180 mm – 1.680 mm |
