Additional information
Modello | K500140 |
---|---|
Max. delivery | 6 l/min |
Air pressure range | 3-7 bar / 40-100 psi |
Max. fluid outlet pressure | 231 bar – 3.350 psi |
Delivery per cycle | 100 cc |
Air consumption at 60 cycles / min | 3 bar – 760 l/min |
Air supply inlet | 3/4″ BSPP (F) |
Fluid outlet | 1″ BSPP (F) |
Materiale pompante | Stainless steel 420B – Acciaio al carbonio |
Piston material | Stainless steel 420B |
Seals material | PTFE + PE 1000 |
Effective motor diameter | Ø 6 1/2″ – 162 mm |
Piston stroke | Ø 4″ – 100 mm |
Max. temperatura d'esercizio | 80 °C |
Capacità fusto | 30 l |
Max. altezza fusto | 480 mm |
Piatto premente | Cod. 510750 |
Elevatore pneumatico | Cod. 510090/5 |
Altezza sistema completo | 1.060 mm – 1.560 mm |
